HEXI MONO M7+
The HEXI M7+ puts you in control by being available to exact your specification
Powered by high efficiency single colour LEDs HEXI M7+ luminaires through a wide range of optics allows you to select just the right configuration for your application.
HEXI M7+ cells can be factory linked allowing incremental increase in luminosity suit your requirement.
HEXI control options include remote 24 CV dimming, DMX/RDM, Wi-Fi ArtNet.
HEXI Example Configurations
HEXI, the choice is yours.
ULTIMATE HEXABILITY
The example left/above shows HEXI M7+ PinStar luminaires with 4 degree hard edge optics and populated with 2700 Kelvin Filament-White LEDs.
ULTIMATE HEXABILITY
HEXI M7+ units are super efficient, the example below/right shows two single HEXI M7+ luminaires with 6 degree optics. The left unit is populated with 2700 Kelvin Filament-White LEDs, whilst the unit on the right is equipped with 465 nanometer blue LEDs. The fixture to eave height is 3 stories 7.5m
DYNAMIC EVENTS
The high flexability of HEXI makes it ideal for entertainment applications, from shows to television.
HEXI Models
HEXI LED Colour Options
HEXI Optic Options
HEXI Control / Power Options
HEXI PHYSICAL
Depth 75mm (max 500mm custom to order)
Bracketry: Powder coated alluminium
IP44 (2mm front optic)
IP67 (8mm front optic and gaskets)
HEXI IP OPTIONS
IP22 | Cost-Effective Choice for Indoor Protection
When selecting equipment for indoor environments, achieving the right balance between adequate protection and cost is crucial. The IP22 rating often emerges as a highly cost-effective solution, providing essential safety without the expense of over-specified protection.
IP44 | Undercover Outdoor & Sheltered Areas
When you need to install electrical fixtures or equipment in locations that are “undercover” – sheltered from direct weather but still exposed to some outdoor elements. Offers an ideal and practical level of protection.
IP67| Robust Protection for Demanding Exterior Environments
To withstand the harsh realities of outdoor use, the IP67 rating signifies a high level of environmental protection, offering peace of mind for exterior installations. Devices and enclosures with an IP67 rating are built to resist significant exposure to both dust and water.
