HEXI

  • Hexagonal, scalable LED luminaires
  • MONO, QUAD, PIXEL, DUOTEK or UV LEDs
  • DMX, Wi-Fi or remote 24CV dimming
  • Low Voltage or Mains supply
  • Lens optics from 3° to 36°
  • Linkable to incrementally increase power
  • Alluminium extrusion body
  • Integral snoot option
  • Yoke or pendant suspension
  • Custom powder coating

HEXI

HEXI from AXALIGHT is a luminaire range designed to be super HEXIBLE.

HEXI puts you in control by being available to your specification in literally thousands of bespoke configurations.

From high efficiency single colour luminaires through to pixelated colour control, along with a wide range of optics allows you to select just the right configuration for your application.

HEXI cells are factory linked allowing you incremental increase in luminosity suit your requirement. Combinations of different types of HEXI cells be combined to create multipurpose luminaires with hybrid LED technologies.

HEXI control options include remote 24 CV dimming, DMX/RDM, Wi-Fi Artnet.

Z

HEXI Example Configurations

HEXI PINSTAR MV

4 degree beam, 4000K, 4.2W, mains power, anthracite power coating with mounting yoke, IP22

HEXI 7XQ7 CV

Seven cell Q7 QUAD RGBW, 120W, 24CV, 6 degree optics, 50mm deep, yoke mounting, silver finish, IP67

HEXI M7+ CV

MONO7+ 2700K, 6 degree optics, 17W 24CV, 50mm deep, yoke mounting, silver finish, IP22

HEXI, the choice is yours.

ULTIMATE HEXABILITY

The example left/above shows HEXI P1 PinStar luminaires with 4 degree hard edge optics and populated with 2700 Kelvin Filament-White LEDs.

ULTIMATE HEXABILITY

HEXI M7 units are super efficient, the example below/right shows two single HEXI M7 luminaires with 6 degree optics. The left unit is populated with 2700 Kelvin Filament-White LEDs, whilst the unit on the right is equipped with 465 nanometer blue LEDs. The fixture to eave height is 3 stories 7.5m

d

HEXI Models

HEXI M7
MODEL
HEXI MONO 7
APPLICATION
High Efficency Single Colour Illumination
LEDs
7 x White, Red, Green, Blue or Yellow
LED POWER
8.4 Watts
FLUX (White@full)
1,100 lumens
EFFICIENCY (all@full)
130 lumens/Watt
HEXI M7+
MODEL
HEXI MONO 7+
APPLICATION
High Efficency Single Colour Illumination
LEDs
7 x White, Red, Green, Blue or Yellow
LED POWER
16.8 Watts
FLUX (White@full)
2,200 lumens
EFFICIENCY (all@full)
130 lumens/Watt
HEXI Q7
MODEL
HEXI QUAD 7
APPLICATION
Saturated Dynamic Colour Control
LEDs
7 QUAD RGBW or RGBA
LED POWER
14 Watts
FLUX (White@full)
630 lumens
EFFICIENCY (all@full)
45 lumens/Watt
HEXI Q7+
MODEL
HEXI QUAD 7+
APPLICATION
Saturated Dynamic Colour Control
LEDs
7 QUAD RGBW
LED POWER
16.8 Watts
FLUX (White@full)
756 lumens
EFFICIENCY (all@full)
45 lumens/Watt
HEXI DT28
MODEL
HEXI DuoTek 28
APPLICATION
Hybrid High Efficent White & Colour Control
LEDs
14 White + 14 TriRGB
LED POWER
8 Watts
FLUX (White@full)
680 lumens
EFFICIENCY (all@full)
85 lumens/Watt
HEXI PS1
MODEL
HEXI PINSTAR
APPLICATION
Narrow Hard Edge Beam
LEDs
1 x White
LED POWER
8.4 Watts
FLUX (White@full)
270 lumens
EFFICIENCY (all@full)
130 lumens/Watt
HEXI PIX7
MODEL
HEXI PIX 7
APPLICATION
Pixel Mapping
LEDs
7 x TriRGB or TriWWW
LED POWER
2 Watts
FLUX (White@full)
70 lumens
EFFICIENCY (all@full)
35 lumens/Watt

HEXI LED Colour Options

HEXI M7/M7+
HEXI Q7
HEXI Q7+
HEXI DT28
HEXI PS1
HEXI PIX7
MODEL
HEXI MONO 7/7+
HEXI QUAD 7
HEXI QUAD 7+
HEXI DuoTek 28
HEXI PINSTAR
HEXI PIX 7
W+RGB
-
-
-
-
-
RGBW
-
-
-
-
RGBY
-
-
-
-
-
RGB
-
-
-
-
2500°K
-
-
-
-
2700°K
-
-
-
3000°K
-
-
-
4000°K
-
-
-
6500°K
-
-
-
RED
-
-
-
GREEN
-
-
-
BLUE
-
-
-
YELLOW
-
-
-

HEXI Optic Options

HEXI M7
HEXI Q7
HEXI DT28
HEXI PS1
HEXI PIX7
MODEL
HEXI MONO 7
HEXI QUAD 7
HEXI DuoTek 28
HEXI PINSTAR
HEXI PIX 7
-
-
-
-
-
-
-
12°
-
--
24°
-
-
-
36°
-
-
-
15x60°
-
-
-
FROST
-
CLEAR
-
g

HEXI Control / Power Options

HEXI M7
HEXI Q7
HEXI DT28
HEXI PS1
HEXI PIX7
MODEL
HEXI MONO 7
HEXI QUAD 7
HEXI DuoTek 28
HEXI PINSTAR
HEXI PIX 7
CONSTANT VOLTAGE
(12V)
-
DMX RDM
CLOUD DRIVE
24V POWER
MAINS POWER
MAINS NON-DIM
-
-
-
1

HEXI PHYSICAL

DIMENSIONS
WEIGHT
MATERIALS
INGRESS
HEXI SINGLE CELL
111mm apex to apex, 97mm face to face
Depth to order (max 500mm)
375 grams (50mm deep body including bracketry)
Body: Alluminium extrusion matt annodised
Bracketry: Powder coated alluminium
IP22 (without front optic)
IP44 (2mm front optic)
IP67 (5mm front optic and gaskets)
